SECTION 3 - M. FRAME, ADJ. RING, TRAMP REL. & CLRNG JACK ASSY

MP SERIES CONE CRUSHER TECHNICAL REFERENCE MANUAL

3-33

Figure 3-26 Clamping Cylinder Hose Connections

Callout Description Callout Description

1 Centerline of countershaft 4 Hose

2 Ø 50 mm (2") hole in clamp ring 5 Adjustment ring

3 Clamping cylinders 6 Hose guard

MP800

MP1000
