SECTION 4 - COUNTERSHAFT, CTRSHAFT BOX & SHEAVE ASSEMBLIES

4-4

MP SERIES CONE CRUSHER TECHNICAL REFERENCE MANUAL

Figure 4-3 Countershaft, Countershaft Box and Sheave Assembly (MP1000)

Callout Description Callout Description

1 Pinion 8 Countershaft

2 Wear ring 9 Countershaft box

3 O-ring 10 Oil flinger

4 Box guards 11 Flinger housing

5 Box shield 12 Rectangular seal

6 Bushing 13 Countershaft bushing RTD

7 Sheave assembly

1 3 2 12 4 5

6 13
