9.2 Wide-angle diffuser
With the wide angle diffuser , focal lengths of
12mm or more can be illuminated (35 mm format).
Pull the wide-angle diffuser out from the reflector
as far as it will go, and then release it.
The wide-angle diffuser automatically folds
downwards. The reflector automatically moves to
the required position.
The automatic adjustment of the motor-zoom reflec-
tor
햳
is not activated if the wide-angle diffuser is
in use.
To insert the wide-angle diffuser , turn it upwards
90° and push it all the way in.
9.3 mecabounce Diffuser MBM-04
If the mecabounce (optional accessories, see 18) is
fitted to the reflector of the flash unit, the reflector
is automatically guided to the position required.
The distance data and zoom factor are corrected to
16 mm.
The automatic adjustment of the motor-zoom
reflector is not activated if the mecabounce is in
use.
The simultaneous use of the wide-angle diffuser
and the mecabounce is not possible.
+
+
