Meunier Technologies DICE DS - Parts List

© Meunier Technologies Inc. 2021 - All rights reserved 13
Parts List
PART
NO.
DESCRIPTION
1
MONO BLOCK
2
CARRIER
3
STEM
4
BALL
5
STEM NUT
6
SEAT
7
O-RING – CARRIER
8
O-RING – SEAT
9
O-RING – STEM
10
O-RING – STEM NUT
11
VALVE HANDLE
12
HANDLE SET SCREW
13
BP/PR TOP BODY
14
SPRING BOTTOM SEAT
15
SPRING TOP SEAT
16
DIAPHRAGM
17
SPRING
18
SOCKET HEAD SCREW
19
ADJUSTMENT SCREW
20
HEX NUT
21
PR/BP WASHER
22
SLEEVE CONE ADAPTER
23
O-RING – SLEEVE CONE ADAPTER
24
ISOLATOR AND PRESSURE GAUGE
25
MUSHROOM NUT
26
CONNECTOR SOCKET
27
CONNECTOR NPT
28
CONNECTOR HOSE
29
CAP
30
O-RING - CONNECTOR
31
MOUNTING WASHER
32
BLEED VALVE
33
O-RING -BLEED VALVE
Refer to the figures in the Installation and Disassembly and Assembly sections for PART
NO.
Note: 25, 26 and 27 are exemplary connectors. All the connector configurations can be found in
the Model Number nomenclature of the IOM (Installation, Operation and Maintenance Manual).
