3.6 Clamping system
Clampsthatmeetthefollowingrequirementsmustbeused:
 • Minimumclampingwidth40mm
 • Clampingheightfor35mmframeheight
 • Clampingdepth7–11mm
 • Staticrequirementsoftherespectivesite
 • Long-termstableclamps
 • Theclampsmustnottouchthefrontglass.
 • Theclampsmustnotcastshadeonanycells.
 • Theclampsmustnotdamageordeformtheframe
ofthemodule.
 • Clampsmustbeattachedtothesubstructureasspecied
bythesubstructuremanufacturer,includingspecic
hardwareandtorquerequirements.Amaximumtorque
of20Nmmustnotbeexceeded.
 • Themoduleframemustnotberemovedormodied.
Drillingadditionalholesonthemoduleframeisnot
permitted.Changesofanykindwillvoidthewarranty.
Clamp depth
Clamp width
Clamp height
Middle clamp
End clamp
Example of end and middle clamp
