Model 435 Page 31
FRONT AND SIDE DRIVE SHAFT AND RELATED PARTS
KEY PART NO. QTY DESCRIPTION
1 E01774 3 Key, Square -3/8x1-3/8" Long
2 E01184 1 Shaft, Side -191" Long -For Standard Drive & Hydraulic
3 E01181 1 Key, Square -3/8" x 1-1/2" Long
4 E01187 1 Guard, Shaft -51-15/16"
6 E01784 4 Flange 3-Hole 62mm-3
7 E01782 4 Bearing, FH206-20G-1-1/4" Greaseable
8 E01780 4 1-1/4" Flange, 3-Hole 62mm-3-90°-Z-Greaseable
9 E01786 4 1-1/4" FH206-20G Bearing w/Flanges Complete
10 E01197 1 Guard, Shaft -33-1/4" Long
13 REF 4 Collar, (not sold separately)
14 E01199 1 Guard, Shaft -57-3/8" Long
15 E01200 2 Bolt, Shear -Grade 2 -3/8"x1-1/4"
16A E01201-10 1 Chain, Front Drive Roller (#60H-122 Pitch), 1,000 RPM Only
16B E01201 1 Chain, Front Drive Roller (#60H-120 Pitch), 540 RPM Only
18 E00307-10 1 Bracket, Front Chain Tightener
19 E00311-00 1 Rubber Front Chain Tension Roller
20 E01798 1 Sprocket, Front Drive, 60B20 x 1-1/4", 3/8" K.W.
23 E01205 2 3/8" Jam Nut, Shear Bolt
24 E01206 1 Hub, Front Shear -3/8" x (1-1/4" Bore)
25A EMC-48 1 60A34 Sprocket, Side Shaft Drive, 1-1/4" Bore, 1,000 RPM Only
25B E01801 60A30 Sprocket, Side Shaft Drive, 1-1/4" Bore, 540 RPM Only
27 E01802 1 Shaft, Front Drive -33-1/2" Long
28 REF 1 Shaft, PTO Drive (see separate listing)
29 E01209 1 Guard, Shaft -33-1/8" Long
30 E01803 3 1-1/4" HC20720 Bearing w/Flanges Complete
31 E01804 3 1-1/4" Flange, 3-Hole 72mm-3-90°-Z-Greaseable
32 E01805 3 Flange, 3-Hole -72mm-3
33 E01806 3 Bearing, HC20720-1-1/4" H.D. Greaseable
34 REF 3 1-1/4" H.D. Collar (not sold separately)
35 E00313 1 Front Chain Tension Spring Only
36 E01647-10 1 Eyebolt, Tensioner 6-1/4"
37 E20934 1 Shoulder Bolt, Tension Arm
