Model 435 Page 33
APRON PARTS
KEY
PART NO. QTY DESCRIPTION
1 E02026-435 2 Apron, One Side Complete -#67P11 -21 Slats/245 Links (per side)
2 E02027 490 Link, 67P11
3 E02028-435 42 Slat w/Links, Overall 27.00" O.A.
4 E02005-390 2 Bearing, Bronze
5 VB-00181 1 Key, Gearbox 1/2" x 1/2" x 5"
6 E02017 2 Holder, Bearing
7 E00242-00 4 Sprocket, Apron -#67-7Tooth
8 E01501-435 1 Shaft, Apron -2" Stress Proof
9 4 Chain Return Slide
10 E00238 4 Key, Square 1/2x2-1/4"
11 E02015-435 2 Shield, Apron Drive Shaft
12 435-52 1 Holder, Center Bearing
12A E20733-06 1 Nipple, Sch40, 1/8 NPT Blk 4"
12B 66270 1 Steel Coupler 1/8" Blk
12C VB-00031 2 BCMP MELBW 3/16" T x 1/8 M Brass Comp 90° Elbow
12D 1 Tube - 49"
12E E20730 1 Zerk, 1/8 NPT Str
13 E02024-11 1 Tightener Weldment, RH
14 E02034 4 Roller, Nylon
15 E02035 4 Pin, Cotter
16 E20728 4 Washer, Machinery
17 E02020-11 6 Nut, 3/4" NC
18 2 Bolt, 3/8-16x1
19 2 Washer, 3/8 Flat
20 2 Nut, 3/8-16
21 E02038-11 1 Tightener, Complete, RH
22 E02039-11 1 Tightener, Complete, LH
23 E02037-11 1 Tightener Weldment, LH
24 1 Bolt, 3/4-10x2-3/4
25 E02040-11 1 Tightener Weldment, Right Center
26 E02031-11 1 Tightener Weldment, Left Center
27 E02032-11 1 Tightener, Complete RH Center
28 E02033-11 1 Tightener, Complete LH Center
29 2 Washer, 3/4 Flat
30 1 Nut, 3/4-10 Nylock
31 E02029-10 2 Spacer, 2"IDx3-3/8" Long Pipe
32 4 Washer, Machinery
33 1 Bearing, Bronze
