Meyer's 435 Tandem - Page 35

Model 435 Page 35
APRON AND LOWER BEATER DRIVE
KEY PART NO. QTY DESCRIPTION
1 E01247-04 1 Shield, Top
2 E01284-10 1 Bracket, Main Gear Case
3 E01300 1 Gear Box, Beater Drive
4 E01272-04 1 Cover, Main Gear Case
5 REF 1
Gear Box, Apron Drive (see Separate Listing)
6 E00509-440 1 Motor, Hydraulic -HB, 2-Bolt w/ Relief 1000psi
7 E00313 1 Spring Clutch Pull
8 E01250 1 Slide Clutch Long Half
9 E01251 1 Slide Clutch Short Half
10 E01253 1 Yoke, Brass
11 E01286-435 1 Shield, Gear Case Side
12 E01287-435 1 Shield, Motor
13 E02004 1 Washer, Flat 1-1/2"
14 E01254 1 Spring Push
15 E01256 1 Clutch Half, Splined
16 E01257 1 Clutch Half, Keyed
17 E00016 1 Lock Assy Complete
18 E01273 1 Hinge
19 E01274 1 Door Stop
20 E01275 1 Shaft Collar, Split
24 VB-00016-440 1 Mounting Plate, Gearbox
