Model 435 Page 37
APRON DRIVE GEAR BOX
KEY
PART NO. QTY DESCRIPTION
1 VB-00032-440 1 Housing RT350 9975
2 VB-00033-440 1 Hub 14551
3 VB-00034-440 1 Circlip E 82 9918
4 VB-00035-440 1 Gear Z=49 9974
5 VB-00036-440 2 Bearing 6015 9982
6 VB-00037-440 2 Circlip I 115 9984
7 VB-00038-440 1 Pinion Z=12 8670-5
8 VB-00039 2 Key 12 x 8 x 30 4174
9 VB-00040-440 1 Gear Z=50 8670-4
10 VB-00041-440 2 Bearing 6208 3342
11 VB-00042 3 Circlip I 80 3435
12 VB-00043-440 1 Pinion Z=10 8670-3
13 VB-00044 1 Key 8 x 7 x 25 3396
14 VB-00045 1 Gear Z=43 8670-2
15 Not used
16 VB-00047 2 Bearing 6305 8596
17 VB-00048 2 Circlip I 62 3433
18 VB-00049 1 Pinion Z=28 8670-1
19 VB-00050 1 Bearing 1538
20 VB-00051 1 Circlip E 50 3428
21 VB-00052 2 Oil Plug Ø1" Gas 9175
22 VB-00053 2 Oil Level Indic Ø1" Glass 1831
23 VB-00054 2 Plug 8625
24 VB-00055 2 Plug 8243
25 VB-00056 2 Oil Seal 75/115/10 9983
26 VB-00057 1 Gasket 9977
27 VB-00058 1 Cover 9976
28 VB-00059 8 Screw Hex-Hd M8 x 16 3284
29 VB-00060 1 Gasket 8671
