Model 435 Page 39
5490-0672 GEAR BOX COMPLETE
540 RPM BEATER DRIVE GEARBOX
Used 11/13 and Later
KEY PART NO. QTY. DESCRIPTION
1 70-06130 1 Machined Housing
2 E01302 1 Machined End Cap
3 E21146-W 4 Bolt 5/16-18x3/4 11-20439
4 E21144-W 2 Gear DP 4 Teeth 17 71-06100 w/ 11-40608 Spacer
5 E01309-W 1 Cross Shaft Output Shimming Required 03/06 - 10/13
6 E01879 2 Snap Ring 24-15269
7 19-16593 AR Spacer Kit
8 E01367 4 Bearing Cup (13620)
9 E01366 4 Bearing Cone (13687)
10 E01316 1 Stamping Cover 28-11029 (69 X 9.5)
11 11-61035 2 9.5 X 29 Square Key
12 28-11024 2 Seal (1.50 X 2.721 X 0.375)
13 19-16605 AR Shim Kit - Not Required On E01300-W Box
14 11-40599 2 Spacer
15 24-15265 2 Retaining Ring
16 09-70139 1 Shaft Input
17 11-40608 2 Spacer
18 E21142 3 3/8 NPT Pipe Plug K38
19 11-81051 1 3/8 NPT to 1/8 NPT Bushing
20 E01320 1 1/8 NPT Relief Plug K112
5490-0672 1 Gear Box Complete
