Model 435 Page 41
5490-0685 GEAR BOX COMPLETE
1000 RPM BEATER DRIVE GEARBOX
Used 11/13 and Later
KEY PART NO. QTY. DESCRIPTION
1 E0307-13 1 Housing 70-00166
2 70-16084 1 Machined End Cap
3 11-20439 4 Screw, 5/16-18 X .88, Grade 5
4 71-06105 1 Gear, 21 Teeth/M=5.25
5 71-06106 1 Gear Shaft, 14 Teeth/M=5.25
6 E01309-W 1 Cross Shaft, Output w/ Gear Shimming Required 03/06 - 10/13
7 E01879 2 Retaining Ring, 24-15269
8 19-16593 AR Spacer Kit Not Used On 4190-0532 Box
9 E01367 4 Bearing Cup (13620)
10 E01366 4 Bearing Cone (13687)
11 E01316 1 Stamping Cover, 26-11029 69 X 9.5
12 11-61035 1 9.5 X 29 Square Key
13 28-11024 2 Seal (1.50 X 2.721 X 0.375)
14 24-15265 1 Retaining Ring
15 11-40599 1 Spacer
16 19-16605 AR Shim Kit
17 11-40608 1 Spacer
18 E21142 3 3/8" NPT Pipe Plug K38
19 11-81051 1 3/8 NPT To 1/8 NPT Bushing
20 E01320 1 1/8 - 27 NPT Relief Plug
5490-0685 1 Gear Box Complete
