Model 435 Page 47
BEATERS AND RELATED PARTS
KEY PART NO. QTY. DESCRIPTION
1 REF 1 Gear Box, Beater Drive (see separate listing)
2 E01469-10 1 Coupler, Coarse Splined
3 E01470 1 7/16x5" -GR8 Bolt -w/locking nut
5 E01979 16 Paddle, Beater -SP14
6 E01473-11 1 Beater Only (less paddles) 9” Paddle Mount
7 E01987-R 1 Bearing Assy, GRA106RRB w/Flanges And Guard
7A E01987-L 1 Bearing Assy, GRA106RRB w/Flanges
8 E02124 1 Bracket, Upper Beater, RH
9 E02125 1 Upper Beater w/Weld On Paddles
10 E01978 1 Key, 3/8x3/8x1-3/8 Long
11 E02126 1 Bracket Weldment, Upper Beater, LH
12 E01478-390 1 Bracket, Beater -Left
13 E01986 64 Bolts for Paddles 1/2x1-1/2" -GR5
14 E01985-11 8 RH Beater Ears, Weld On 9”
15 E01984-11 8 LH Beater Ears, Weld On 9”
16 3 Nut, 3/8-16 Flange
17 E02127 1 Angle, Tensioner Anchor
18 E01972-10 1 Sprocket, QD-60SDS22H
19 E02128 1 Roller Chain, 84 Pitches, #60H
20 E00016 1 Lock Assembly, Complete
21 E02129 2 Hinge
22 E02130 1 Door, Upper Beater Drive
23 E00261 1 Bearing
24 E02132-10 1 Sprocket, QD-60SDS20H
25 E01978 1 Key, 3/8x3/8x1-3/8 Long
26 1 Washer, 3/8 Flat
27 E02133 1 HHCS 3/8-16
28 E20944 1 Shoulder Bolt, Tension Arm
29 E02134 1 Tensioner Arm
30 E00313 1 Spring
31 E02135 1 Bushing
32 1 Washer, Flat
33 1 Lock Nut
34 1 Washer, Flat
35 1 Nut
36 E00311-00 1 Rubber Rear Tension Roller
37 E02136 1 Door, Lower, Used w/No Top Beater
38 E02137 1 Hinge, Used w/No Top Beater
39 E02138 1 Bushing, QD-SDS-1-3/8 S
40 E02139 1 Bushing, QD-SDS-1-1/2
41 E01973 1 Bearing Assy FH207-226 1-3/8” w/2-72 mm - 3 Flange
