Model 435 Page 49
APRON DRIVE HYDRAULICS
KEY
PART NO. QTY DESCRIPTION
1 E00509-440 1 Motor, Hydraulic -HB, 2-Bolt w/ Relief 1000psi
2 1 Hose, Flow Line
3 E00484-00 3 Adapter, JIC to O-Ring 6400-8-10
4 E00485-00 1 O-Ring Adapter 6403NWO-10-8
5 E00486-00 1 Valve, Motor Flow Control
6 E00487-00 1 Tee, 6803-8-8
7 E21458 1 O-Ring Adapter 6410-12-8
8 E00489-00 1 Check Valve, LTF-8-OW
9 REF 1 Hose, Hydraulic, 8M3K-8FJX-8MP-92"
10 REF 1 Hose, Hydraulic, 8M3K-8FJX-8MP-92"
11 1 Hose, Return Line
12 E02119 6 Clamp, Tube
13 E02118 6 Bracket, Clamp
14 E00495 1 Hose Handle
15 E00496 1 Hose Control Adapter
16 E00497-00 1 Ball Valve (72-903)
17 E01347-01 1 Control Hose 8G2-8G-8MP-8G-8MP-112"
18 E01321 1 Bracket, Controlled Flow Valve
19 E23579 1 O-Ring to JIC 90° Adapter 6801-8-12
20 E21447 1 O-Ring Adapter 6400-8-8
22 E01117 2 Bracket, Flow Control Valve
23 E00505 1 90° O-Ring Adapter to JIC 6809-8-8
24 E21442 1 O-Ring Adapter to JIC 90° 6801-8-10
27 E01591 2 Quick Couplers
28 E21450 1 Adapter 6400-8-12 O-Ring
30 E21451 1 Tee 6602-8
31 E21452 1 Tee 6804-8-8
32 E01322 Hose/Relief Dump Line 6M3K-6FJX-8FJX-23"
33 E01323 Hose/Flow Control Ex to Return 8M3K-8FJX-8FJX90S-22"
34 E01324 Hose/In 14gpm Control to CF on Flow Control 8M3K-8FJX-8FJX-15"
35 E21456-VB 1 Valve Controlled Flow BG57.5-12SAE
To Next Page
