Meyer Sound UPQ-D Series User Manual

APPENDIX C: UPQ-D SERIES SPECIFICATIONS
42
AMPLIFIER
Type Two-channel, open-loop, Class D
Total Output P ower 2250 W peak
Note: Peak power based on the maximum unclipped peak voltage the amplifier will produce into the nominal load
impedance.
THD, IM TIM <.02%
Cooling Convection
AC POWER
Connectors powerCON 20 input with loop output
Automatic Voltage Selec-
tion
90–265 V AC, 50–60 Hz
Safety Agency Rated
Operating Voltage
100–240 V AC, 50–60 Hz
Turn On/Turn Off Points 90 V AC turn-on, no turn-off; internal fuse protection above 265 V AC
Current Draw
Idle Current 0.27 A rms (115 V AC); 0.25 A rms
(230 V AC); 0.29 A rms (100 V AC)
0.27 A rms (115 V AC); 0.25 A rms
(230 V AC); 0.29 A rms (100 V AC)
0.27 A rms (115 V AC); 0.25 A rms
(230 V AC); 0.29 A rms (100 V AC)
Maximum Long-Term
Continuous Current
2.0 A rms (115 V AC); 1.0 A rms (230
V AC); 2.3 A rms (100 V AC)
2.0 A rms (115 V AC); 1.0 A rms (230
V AC); 2.3 A rms (100 V AC)
2.0 A rms (115 V AC); 1.0 A rms (230
V AC); 2.3 A rms (100 V AC)
Burst Current 3.7 A rms (115 V AC); 1.9 A rms (230
V AC); 4.3 A rms (100 V AC)
3.6 A rms (115 V AC); 1.8 A rms (230
V AC); 4.1 A rms (100 V AC)
3.8 A rms (115 V AC); 1.9 A rms (230
V AC); 4.4 A rms (100 V AC)
Note: AC power cabling must be of sufficient gauge so that under burst current rms conditions, cable transmission
losses do not cause the loudspeaker’s voltage to drop below the specified operating range.
Maximum Instantaneous
Peak Current
8.2 A rms (115 V AC); 4.2 A rms (230
V AC); 9.3 A rms (100 V AC)
7.8 A pk (115 V AC); 4.0 A pk (230 V
AC); 9.1 A pk (100 V AC)
8.4 A pk (115 V AC); 4.1 A pk (230 V
AC); 9.7 A pk (100 V AC)
Inrush Current <20 A peak <20 A peak <20 A peak
RMS NETWORK (OPTIONAL)
Two- conductor twisted- pair network that reports all operating parameters of amplifiers to system host computer.
PHYSICAL
Dimensions W: 19.00 in (483 mm) x H: 28.15 in (715 mm) x D: 18.18 in (462 mm);
Weight 95 lb (43 kg)
Enclosure Premium multi-ply birch with slightly textured black finish
Protective Grille Powder-coated, hex-stamped steel with black mesh
Rigging Aluminum end plates on top and bottom with metric M10 threaded points; integral 1-1/2 in (38 mm) pole mount
receptacle on bottom
