MFJ-1278B MULTI-MODE OPERATIONAL COMMANDS
The PIXTONES values are in Hexidecmal format. If the picture transmitted does not seem
to have the right contrast, try reseting the PIXTONES values.
The HEX values that represent the PIXTONES for the pictures to be transmitted are listed in
Table below:
PIXTONES Values
(In HEX)
FAX/SSTV
TransmitTones (Hz)
$86 1100 sync
$8E 1200 "
$92 1300 "
$AC 1500 "
$9D 1550 White
$AD 1600 "
$B0 1650 "
$B2 1700 "
$B6 1750 "
$B5 1800 Light Gray
$B3 1850 "
$B8 1900 "
$BC 1950 "
$BA 2000 "
$BE 2050 Dark Gray
$B9 2100 "
$BD 2150 "
$BB 2200 "
$BF 2250 Black
