MFJ-1278B MULTI-MODE BASIC OPERATION
On the CW, MCW and Memory Keyer operation modes, instead of selecting a baud rate you
will select CW sending speed by entering a number from 5 thru 99. If you do not select a
speed, the MFJ-1278B will use the last speed selected. The default value is 20 WPM.
MODE
CODE
OPERATION
MODE
DEFAULT
BAUD RATE
SELECTABLE
BAUDRATE/SPEED/FORMAT
VP
VHF Packet 1200
300, 1200, 2400*, 9600*
HP
HF Packet 300 300
PT
Pactor 100 100, 200
VB
VHF Baudot RTTY 45 45, 50, 57, 75, 100, 110,150, 200, 300
HB
HF Baudot RTTY 45 45, 50, 57, 75, 100, 110,150, 200, 300
VA
VHF ASCII RTTY 110 45, 50, 57, 75, 100, 110,150, 200, 300
HA
HF ASCII RTTY 110 45, 50, 57, 75, 100, 110,150, 200, 300
AM
AMTOR/NAVTEX 100 100
CW
CW/ Mem. Keyer 20 5 WPM thru 99 WPM
MC
Modulated CW 20 5 WPM thru 99 WPM
FX FAX(2-level)**
3(120L/M) 60, 90, 120, 180, 240, 360, 480 (LPM)
FAX(16-level)***
TV SSTV**
1 (8.5S) 8.5, 12, 17, 24, 36(s)
Color SSTV***
-------- Robot 72, Scotty 1, 2 Martin 1, 2
Table 4-3: MODE Command Codes and Baud Rates.
* With optional internal modem
** Supported by the built-in printer port: 2-level FAX and 4-level B&W SSTV.
*** When using MFJ Multicom terminal program MFJ-1278B will support 16-level FAX
and Color SSTV.
Radio Port Switching
The MFJ-1278B provides the user with two independent radio ports, Radio 1 and Radio 2.
The MFJ-1278B selects Radio port 1 when first initialized. After receiving the cmd:
command prompt, you can select the desired radio port by typing "RAD 1" or "RAD 2"
followed by a "Return" key press.
MFJ-1278B will display a new operation status and end with cmd: prompt.
MEMORY BUFFERS
The MFJ-1278B gives you ten user programmable memory buffers. The Memory Buffers are
numbered 0 thru 9. These Memory Buffers are accessible by the BUF command. Each
memory buffer is capable of storing up to 120 characters, including puncuations. The user
