Table 5a. Esprit Models 3 and 4 Rack UPS Specifications (Continued)
Item Specification Comment
Design standards Safety; UL, cUL 1778, Emissions;
FCC A, Surge protection; ANSI
C62.41, Transportation; (drop test),
IEC 68 level 1, (vibration), IEC
68.2-6 level 3, testing; PowerCet
tested
Input connection NEMA 5-30/50 w/ six foot cord
Output connections 1 NEMA 5 30/50 and 4 5-15
Auxiliary DC input 1 each special female connector on Provides additional battery time
UPS (18" cord and male connector
on optional battery)
Size 1 each (UPS, battery) 5.25" X 7.25" X 19"
Weight 65/70 lbs.. total
MTBF 200K hours
Sizing Guide and Battery Runtimes (In minutes, 0.62 PF)
Unix Server 1 2 3 4
server servers servers servers
PC Server 1 2 3 4 5 6 7 8
server servers servers servers servers servers servers servers
VA 500 1000 1500 2000 2500 3000 3500 4000
Esprit 3 SLR 90 40 28 19 11 6
Esprit 3 SLR
+ 1 Ext. Batt. 240 90 40 28 19 15
Esprit 3 SLR
+ 2 Ext. Batt. 360 150 90 60 45 38
Esprit 4 SLR 120 50 30 20 15 12 9 7
Esprit 4 SLR
+ 1 Ext. Batt. 240 100 72 45 35 28 24 18
Esprit 4 SLR
+ 2 Ext. Batt. 360 180 110 75 55 45 35 29
Extended Battery Runtime (internal plus extended battery, in minutes, 0.7 PF)
Extended Batteries (Qty.) 1 2 3 4
Model
Esprit 3 12 30 45 60
Esprit 4 15 25 38 49
Note: All battery times above are typical.
5—2
