5.0 Technical Data
Technical Data Units
16 H &
HS
27 H &
HS & (S)
47 H &
(S)
75 & 77
H & HM
Nominal Heat Input Net Min/Max kW 4.0/15.0 6.5/25.0 12.0/45.0 15.0/70.0
Nominal Heat Input Gross Min/Max kW 4.4/16.5 7.2/27.5 13.2/49.5 16.5/77.0
Carbon Emissions
100% Of max Output
G20
G31
kgC/kWhr
Min/Max kW 4.3/15.8 7.0/26.2 12.9/47.0 16.0/74.6
Design Flow Rate (50ºC/30ºC) Ltr/sec 0.188 0.312 0.560 0.880
Nominal Heat Output (80ºC/60ºC)
Min/Max kW 3.7/14.5 6.3/24.2 11.7/43.5 14.5/67.8
Design Flow Rate (80ºC/60ºC) Ltr/sec 0.172 0.288 0.519 0.807
Hot Water Generation Output kW (31.3) (45)
Hot water flow rate @ DT 30
)
C Ltr/min (15) (20)
Min Flow Rate For H/W Activation Ltr/min (3) (3)
Maximum Secondary Water
Pressure
bar (10) (10)
Minimum Flow Rate Ltr/sec 0.125 0.246 0.373 0.592
Residual Head from In-built Pump m/W.C 3.7 1.3 0.5 0.75
Maximum Input Gas Rate
G20
G31
m³/hr
m³/hr
1.55
0.57
2.55
1.00
4.65
1.72
6.91
2.60
Gas Inlet Pressure Min/Max Mbar 18.0/50.0 18.0/50.0 18.0/50.0 18.0/50.0
Maximum Flue Gas Volume (Hot) m³/hr 21.36 40.81 64.08 96.84
Available Fan Pressure Pa 400 400 400 400
Maximum Water Pressure (Hot) bar 3.0 3.0 3.0 3.0
Minimum Water Pressure (Cold) bar 0.8 0.8 0.8 0.8
Maximum Flow Temperature ºC 90 90 90 90
Power Supply (230 V / 50 Hz) Amps 5 5 5 5
Max Power Consumption Watts 122 129 145 250
Water Content Ltrs 4 5.2 5.2 8.2
Lift Weight (Dry) kg 43.0 43.0 43.0 70.0
Flue Connection
Flue Gas Outlet Female 80mm 80mm 80mm 80mm
Combustion Air Inlet Male 125mm 125mm 125mm 125mm
Concentrically Configured
(Straight or Elbow Adapter Required.)
Yes Yes Yes Yes
