simulation
7170
Telephone customer
service
IO test
Used to check inputs and
outputs
Line no. Data point Value Unit
7700 Relay test No test
7730
Outside temperature
B9
------- °C
7732 Flow temperature B1 ------- °C
7750 DHW temperature B3 ------- °C
7760
Boiler temperature
B2
------- °C
7820
Sensor temperature
BX1
23.1 °C
7821
Sensor temperature
BX2
------- °C
7830
Sensor temperature
BX21 module 1
------- °C
7831
Sensor temperature
BX22 module 1
------- °C
7832
Sensor temperature
BX21 module 2
------- °C
7833
Sensor temperature
BX22 module 2
------- °C
7840 Voltage signal H1 0 V
7841 Contact state H1 Open
7845 Voltage signal H2 0 V
7846 Contact state H2 Open
7870 Signal burner fault S3 0V
7881
Signal 1st burner
stage E1
0V
Status
Line no. Data point Value Unit
8000
Status heating circuit
1
Room frost protection
active
8001
Status heating circuit
2
---
8002
Status heating circuit
P
---
8003 Status DHW ---
8004
Status cooling circuit
1
---
8005 Status boiler ---
8007 Status solar ---
8008 State solid fuel boiler ---
8010 Status buffer ---
8011 Status pool ---
Diagnostic Cascade
