Mi 2 Lite - Page 7

Align the center hole of fan blade assembly with the motor's sha and
install it onto the sha, then install fan blade assembly knob onto the
motor's sha. Turn the knob counterclockwise in order to fix the fan blade
assembly to the motor's sha.
Step 3: Install the rear grille
5
Installation Instructions
Step 2: Open the fan assembly
①
②
Fan Assembly
Front Grille
Fan Blade Assembly
Rear Grille
Disassemble fan assembly as shown in the figures below: ①Turn the
front grille counterclockwise until the grilles are properly loosened. ②
Then remove front grille from rear grille and take out fan blade
assemby.
Step 4: Install the fan blade assembly
Make sure “ ” points up when installing rear grille onto the motor,
and turn rear grille knob clockwise to tighten the rear grille to the motor.
2
11
12 13
11
1213
2
13
13
6
6
12
5
12
5
