6
©2020 Micro-Air, Inc. July 22, 2020 Revision 1.07
6. Insert the thermostat mounting pins into the back of the thermostat in the provided holes while
pressing it against the wall. Press down gently with the thermostat flush against the wall to lock
down the thermostat.
Operation
Image Icons
Image icons are displayed on your screen as touch/press areas. A complete list of them is provided in
Appendix I of this document. They are organized to show related icons with functions described in the
text below. We recommend setting the home, away, or schedule operation first. Next set the desired
operating mode such as cool only or a heating mode. Finally set the fan speed and desired set point.
Basic operations
Cool, heat strip, heat pump, and furnace
aqua modes are available based on system
configuration. Press the image icon to select a different operating mode.
Automatic modes switch between cooling and the
to maintain temperature. These modes are available based on the heating modes
offered by your system.
Fan speed can be selected between low
medium (if available), and
automatic. Automatic changes fan speeds as required for improved comfort.
provide three different thermostat
experiences.
Home: Traditional way a thermostat operates, changing at a specific setpoint.
Away: Provides two set points allowing a wider range of temperatures. Set
your desired auto mode, if available.
Schedule: Allows changing the temperature up to four times each day.
The power button icon on the top right of the
thermostat turns the system off and on.
Additional settings and scheduled temperature changes are available when the
thermostat is off.
