MCS‐BMS‐GATEWAYStartupGuide Revision4.0
MicroControlSystems5580EnterprisePkwy,FortMyers,FL33905USAWeb:www.mcscontrols.com
Tel:(239)6940089Fax:(239)6940031
39

Light Description
PICERR
(LED6)
ThePICERRLEDwillgoonsolidindicatingthereisaPICerror.
LON‐TX
LED
OnnormaloperationofMCS‐BMS‐GATEWAY,theTXLEDwillflashwhenamessageissentonthe
LonportoftheMCS‐BMS‐GATEWAY.
LON‐RX
LED
OnnormaloperationofMCS‐BMS‐GATEWAY,theRXLEDwillflashwhenamessageisreceivedon
theLonportoftheMCS‐BMS‐GATEWAY.
LON‐SRV
LED
(nextto
Lonport)
TheLON‐SRVLEDwillflashiftheMCS‐BMS‐GATEWAYisconfiguredforimplicitaddressingandnot
commissioned.LEDwillbeoffiftheMCS‐BMS‐GATEWAYisconfiguredforimplicitaddressingand
commissionedorifitisconfiguredforexplicitaddressing.
LED7
Notused
LED8
Notused



















