MCS Total

Solution

for all your

Control

Needs

Energy Ecient and

RoHS Compliant

5580 Enterprise Pkwy.

Fort Myers, FL 33905

O󰀩ce: 239-694-0089

Fax: 239-694-0031

www.mcscontrols.com

BMS COMMUNICATION

MCS-BMS-GATEWAY

For Interfacing MCS-MAGNUM to:

Building Automation Systems Protocols

MCS, Modbus RTU, Modbus IP, Ethernet,

BACnet IP, BACnet MS/TP, LonWorks, N2,

MCS-MAGNUM

Rev. 3.3

August 17, 2021

Ethernet

Building

Management

System

MCS-Touch

Internet

Router

MCS-BMS-Gateway-NL

RS485 or

LonWorks

Table of Contents

Other manuals for Micro control systems MCS-BMS-GATEWAY

Startup Guide49 pages

Questions and Answers

C
Christopher MillsAug 12, 2025
How to fix communication issues between MCS Magnum and MCS Gateway?
- J
  Joshua WeaverAug 12, 2025
  To resolve communication problems between the MCS Magnum and the MCS Gateway: * Ensure the network cabling is correctly connected. * Verify that the IP address, subnet mask, and default gateway settings of the MCS Magnum match the label on the MCS Gateway. * Examine the LEDs on the Ethernet port; the yellow LED should be solid, and the green LED should flash continuously.
S
Shannon DunlapAug 19, 2025
What to do if there is a configuration error on the MCS Gateway by Micro control systems?
- K
  Kelly ChenAug 19, 2025
  If a configuration error occurs on the MCS Gateway, refer to the Error Screen in the Remote User Interface for a description of the specific error.
M
Michelle FrenchAug 27, 2025
What to do if I see a communication error on the MCS Gateway by Micro control systems?
- W
  William SaundersAug 27, 2025
  If a communication error occurs on the MCS Gateway, go to the error screen of the RUI interface to determine the cause of the error.
S
Stephanie HenrySep 2, 2025
What to do if system error occurs on Micro control systems Gateway?
- J
  Jeremy WaltonSep 2, 2025
  If a system error occurs on the MCS Gateway, immediately report the related “system error” shown in the error screen of the RUI interface to Micro Control Systems for evaluation.

Micro control systems MCS-BMS-GATEWAY Specifications

General

Power Supply	24 VDC
Operating Temperature	-20°C to +60°C
Weight	200g
Protection Class	IP20
Protocols	Modbus RTU, Modbus TCP
Ethernet	10/100 Mbps
Serial Ports	RS-485
