MCS-MAGNUM-BMS REVISION 3.1
8
Analog Output Points are read-only. Output numbering is based upon SI16-AO4 hardware type board. Notable BACnet
properties available: Units
Magnum BACnet ID BACnet Name Modbus Register N2
Analog Out M-1 AO:1 Refer to Cong *30201 *AO: 1
Analog Out M-2 AO:2 Refer to Cong *30202 *AO: 2
Analog Out M-3 AO:3 Refer to Cong *30203 *AO: 3
Analog Out M-4 AO:4 Refer to Cong *30204 *AO: 4
Analog Out 1-1 AO:5 Refer to Cong *30205 *AO: 5
Analog Out 1-2 AO:6 Refer to Cong *30206 *AO: 6
Analog Out 1-3 AO:7 Refer to Cong *30207 *AO: 7
Analog Out 1-4 AO:7 Refer to Cong *30208 *AO: 8
Analog Out 2-1 AO:8 Refer to Cong *30209 *AO: 9
Analog Out 2-2 AO:10 Refer to Cong *30210 *AO: 10
Analog Out 2-3 AO:11 Refer to Cong *30211 *AO: 11
Analog Out 2-4 AO:12 Refer to Cong *30212 *AO: 12
Analog Out 3-1 AO:13 Refer to Cong *30213 *AO: 13
Analog Out 3-2 AO:14 Refer to Cong *30214 *AO: 14
Analog Out 3-3 AO:15 Refer to Cong *30215 *AO: 15
Analog Out 3-4 AO:16 Refer to Cong *30216 *AO: 16
Analog Out 4-1 AO:17 Refer to Cong *30217 *AO: 17
Analog Out 4-2 AO:18 Refer to Cong *30218 *AO: 18
Analog Out 4-3 AO:19 Refer to Cong *30219 *AO: 19
Analog Out 4-4 AO:20 Refer to Cong *30220 *AO: 20
*- Indicates value multiplied by 10 to include one decimal place. (I.e. BMS value of 500 indicates actual value 50.0)
1.4. Setpoints
Setpoints are read-only. Notable BACnet properties available: Units
Magnum BACnet ID BACnet Name Modbus N2
Setpoint #1 AV:0 STP# 1-<Setpoint name> 40301 ADF:1
Setpoint #21 AV:88 STP# 21-<Setpoint name> 40321 ADF:89
Setpoint #163 AV:230
STP# 163-<Setpoint
name>
40463 ADF:231
1.5. Chiller/Compressor States
State values are read-only. Notable BACnet properties available: Number of States, State-Text (Contains character text
of current state)
Magnum BACnet ID BACnet Name Modbus Register N2
Chiller Unit State MV:0 CHILLER STATE 30306 BYT:1
Compressor #1 State MV:1 COMPRESSOR #1 STATE 30307 BYT:2
Compressor #2 State MV:2 COMPRESSOR #2 STATE 30308 BYT:3
