NOTE: When setting DIP Switches, please ensure that power to the board is OFF.
3.3.5.1. Baud Rate DIP Switch Selection
Baud B0 B1 B2 B3
Auto
Off Off Off Off
110
On Off Off Off
300
Off On Off Off
600
On On Off Off
1200
Off Off On Off
2400
On Off On Off
4800
Off On On Off
9600
On On On Off
19200
Off Off Off On
20833
On Off Off On
28800
Off On Off On
38400
On On Off On
57600
Off Off On On
76800
On Off On On
115200
Off On On On
