1.3. Relay Output Points
Relay Output points are read-only. Output numbering is based upon MCS-RO-10 (MCS-RO BASE, MCS-RO-EXT)
hardware type board
Magnum BACnet ID BACnet Name Modbus N2
Relay M–1 BO: 1 Refer to Cong 00001 BO: 1
Relay M–2 BO: 2 Refer to Cong 00002 BO: 2
Relay M–3 BO: 3 Refer to Cong 00003 BO: 3
Relay M–4 BO: 4 Refer to Cong 00004 BO: 4
Relay M–5 BO: 5 Refer to Cong 00005 BO: 5
Relay M–6 BO: 6 Refer to Cong 00006 BO: 6
Relay M–7 BO: 7 Refer to Cong 00007 BO: 7
Relay M–8 BO: 8 Refer to Cong 00008 BO: 8
Relay M–9 BO: 9 Refer to Cong 00009 BO: 9
Relay M-10 BO:10 Refer to Cong 00010 BO: 10
Relay 1–1 BO:11 Refer to Cong 00011 BO: 11
Relay 1–2 BO:12 Refer to Cong 00012 BO: 12
Relay 1–3 BO:13 Refer to Cong 00013 BO: 13
Relay 1–4 BO:14 Refer to Cong 00014 BO: 14
Relay 1–5 BO:15 Refer to Cong 00015 BO: 15
Relay 1–6 BO:16 Refer to Cong 00016 BO: 16
Relay 1–7 BO:17 Refer to Cong 00017 BO: 17
Relay 1–8 BO:18 Refer to Cong 00018 BO: 18
Relay 1–9 BO:19 Refer to Cong 00019 BO: 19
Relay 1- 10 BO:20 Refer to Cong 00020 BO: 20
Relay 2–1 BO:21 Refer to Cong 00021 BO: 21
Relay 2–2 BO:22 Refer to Cong 00022 BO: 22
Relay 2–3 BO:23 Refer to Cong 00023 BO: 23
Relay 2–4 BO:24 Refer to Cong 00024 BO: 24
Relay 2–5 BO:25 Refer to Cong 00025 BO: 25
Relay 2–6 BO:26 Refer to Cong 00026 BO: 26
Relay 2–7 BO:27 Refer to Cong 00027 BO: 27
Relay 2–8 BO:28 Refer to Cong 00028 BO: 28
Relay 2–9 BO:29 Refer to Cong 00029 BO: 29
Relay 2 -10 BO:30 Refer to Cong 00030 BO: 30
Relay 3–1 BO:31 Refer to Cong 00031 BO: 31
Relay 3–2 BO:32 Refer to Cong 00032 BO: 32
Relay 3–3 BO:33 Refer to Cong 00033 BO: 33
Relay 3–4 BO:34 Refer to Cong 00034 BO: 34
Relay 3–5 BO:35 Refer to Cong 00035 BO: 35
Relay 3- 6 BO:36 Refer to Cong 00036 BO: 36
Relay 3–7 BO:37 Refer to Cong 00037 BO: 37
Relay 3–8 BO:38 Refer to Cong 00038 BO: 38
Relay 3–9 BO:39 Refer to Cong 00039 BO: 39
Relay 3–10 BO:40 Refer to Cong 00040 BO: 40
Magnum BACnet ID BACnet Name Modbus N2
Relay 4–1 BO:41 Refer to Cong 00041 BO: 41
Relay 4–2 BO:42 Refer to Cong 00042 BO: 42
Relay 4–3 BO:43 Refer to Cong 00043 BO: 43
Relay 4–4 BO:44 Refer to Cong 00044 BO: 44
Relay 4–5 BO:45 Refer to Cong 00045 BO: 45
Relay 4–6 BO:46 Refer to Cong 00046 BO: 46
Relay 4–7 BO:47 Refer to Cong 00047 BO: 47
Relay 4–8 BO:48 Refer to Cong 00048 BO: 48
Relay 4–9 BO:49 Refer to Cong 00049 BO: 49
Relay 4 -10 BO:50 Refer to Cong 00050 BO: 50
Relay 5–1 BO:51 Refer to Cong 00051 BO: 51
Relay 5–2 BO:52 Refer to Cong 00052 BO: 52
Relay 5–3 BO:53 Refer to Cong 00053 BO: 53
Relay 5–4 BO:54 Refer to Cong 00054 BO: 54
Relay 5–5 BO:55 Refer to Cong 00055 BO: 55
Relay 5–6 BO:56 Refer to Cong 00056 BO: 56
Relay 5–7 BO:57 Refer to Cong 00057 BO: 57
Relay 5–8 BO:58 Refer to Cong 00058 BO: 58
Relay 5–9 BO:59 Refer to Cong 00059 BO: 59
Relay 5 -10 BO:60 Refer to Cong 00060 BO: 60
Relay 6–1 BO:61 Refer to Cong 00061 BO: 61
Relay 6–2 BO:62 Refer to Cong 00062 BO: 62
Relay 6–3 BO:63 Refer to Cong 00063 BO: 63
Relay 6–4 BO:64 Refer to Cong 00064 BO: 64
Relay 6–5 BO:65 Refer to Cong 00065 BO: 65
Relay 6- 6 BO:66 Refer to Cong 00066 BO: 66
Relay 6–7 BO:67 Refer to Cong 00067 BO: 67
Relay 6–8 BO:68 Refer to Cong 00068 BO: 68
Relay 6–9 BO:69 Refer to Cong 00069 BO: 69
Relay 6–10 BO:70 Refer to Cong 00760 BO: 70
Relay 7–1 BO:71 Refer to Cong 00071 BO: 71
Relay 7–2 BO:72 Refer to Cong 00072 BO: 72
Relay 7–3 BO:73 Refer to Cong 00073 BO: 73
Relay 7–4 BO:74 Refer to Cong 00074 BO: 74
Relay 7–5 BO:75 Refer to Cong 00075 BO: 75
Relay 7–6 BO:76 Refer to Cong 00076 BO: 76
Relay 7–7 BO:77 Refer to Cong 00077 BO: 77
Relay 7–8 BO:78 Refer to Cong 00078 BO: 78
Relay 7–9 BO:79 Refer to Cong 00079 BO: 79
Relay 7–10 BO:80 Refer to Cong 00070 BO: 80
*- Indicates value multiplied by 10 to include one decimal place. (I.e. BMS value of 500 indicates actual value 50.0)
