Micro control systems MCS-BMS-GATEWAY - Unit Alarms

MCS-MAGNUM-BMS REVISION 3.1
12
1.7. Unit Alarms
Modbus Info Bacnet Object Idener V17 Frimware
Unit Alarms Funcon Type Register
Bacnet Object
Type
Address
Relay
output
Modbus Bacnet
EMERGENCY_STOP 04:input Register 31011 AV: Ananlog Value 1296 HVAC//RTU HVAC//RTU HVAC//RTU
FREEZE_PROTECTION 04:input Register 31012 AV: Ananlog Value 1297 HVAC//RTU HVAC//RTU HVAC//RTU
HIGH_SUMP_TEMP 04:input Register 31013 AV: Ananlog Value 1298 HVAC//RTU HVAC//RTU HVAC//RTU
PHASE_LOSS 04:input Register 31014 AV: Ananlog Value 1299 HVAC//RTU HVAC//RTU HVAC//RTU
HIGH_DELTA_TEMP 04:input Register 31015 AV: Ananlog Value 1300 HVAC/ HVAC/ HVAC/
VOLTAGE 04:input Register 31016 AV: Ananlog Value 1301 HVAC//RTU HVAC//RTU HVAC//RTU
SMOKE_ALARM 04:input Register 31017 AV: Ananlog Value 1302 No Support No Support No Support
FIRE_ALARM 04:input Register 31018 AV: Ananlog Value 1303 HVAC//RTU HVAC//RTU HVAC//RTU
COMMON_CONDENSER 04:input Register 31019 AV: Ananlog Value 1304 HVAC//RTU HVAC//RTU HVAC//RTU
CIRCUIT_CONDENSER 04:input Register 31020 AV: Ananlog Value 1305 HVAC//RTU HVAC//RTU HVAC//RTU
Fuild Cooler Fan Fault 04:input Register 31021 AV: Ananlog Value 1306 HVAC//RTU HVAC//RTU HVAC//RTU
PUMP_FAILURE 04:input Register 31022 AV: Ananlog Value 1307 HVAC//RTU HVAC//RTU HVAC//RTU
PROCESS_PUMP_FAILURE 04:input Register 31023 AV: Ananlog Value 1308 HVAC//RTU HVAC//RTU HVAC//RTU
PROCESS_PUMP_LOW_FLOW 04:input Register 31024 AV: Ananlog Value 1309 HVAC HVAC HVAC
BOILER_PUMP_FAULT 04:input Register 31025 AV: Ananlog Value 1310 HVAC HVAC HVAC
BOILER_PUMP_HIGH_AMPS 04:input Register 31026 AV: Ananlog Value 1311 HVAC HVAC HVAC
BOILER_PUMP_LOW_AMPS 04:input Register 31027 AV: Ananlog Value 1312 HVAC HVAC HVAC
BOILER_STAGE_FAULT 04:input Register 31028 AV: Ananlog Value 1313 HVAC HVAC HVAC
HIGH_WATER_TEMP 04:input Register 31029 AV: Ananlog Value 1314 HVAC//RTU HVAC//RTU HVAC//RTU
OVERHEAT_PROTECTION 04:input Register 31030 AV: Ananlog Value 1315 HVAC HVAC HVAC
RTU_SUPPLY_DUCT 04:input Register 31031 AV: Ananlog Value 1316 RTU RTU RTU
RTU_EXHAUST_FAN_FAULT 04:input Register 31032 AV: Ananlog Value 1317 RTU RTU RTU
RTU_MOD_GAS_HEATER_FAULT 04:input Register 31033 AV: Ananlog Value 1318 RTU RTU RTU
RTU_SCR_HEATER_FAULT 04:input Register 31034 AV: Ananlog Value 1319 RTU RTU RTU
RTU_CLOGGED_FILTER 04:input Register 31035 AV: Ananlog Value 1320 RTU RTU RTU
RTU_HIGH_STATIC_PRESSURE 04:input Register 31036 AV: Ananlog Value 1321 RTU RTU RTU
RTU_LOW_STATIC_PRESSURE 04:input Register 31037 AV: Ananlog Value 1322 RTU RTU RTU
BOILER_PUMP_FLOW_FAULT 04:input Register 31038 AV: Ananlog Value 1323 HVAC HVAC HVAC
Leaving Water Temp. Sensor Fault 04:input Register 31039 AV: Ananlog Value 1324 HVAC//RTU HVAC//RTU HVAC//RTU
Reutrn Water Temp. Sensor Fault 04:input Register 31040 AV: Ananlog Value 1325 HVAC//RTU HVAC//RTU HVAC//RTU
Evap Water Pressure In #1 Sensor Fault 04:input Register 31041 AV: Ananlog Value 1326 HVAC//RTU HVAC//RTU HVAC//RTU
Evap Water Pressure Out #1 Sensor Fault 04:input Register 31042 AV: Ananlog Value 1327 HVAC//RTU HVAC//RTU HVAC//RTU
Evap Water Pressure In #2 Sensor Fault 04:input Register 31043 AV: Ananlog Value 1328 HVAC//RTU HVAC//RTU HVAC//RTU
Evap Water Pressure Out #2 Sensor Fault 04:input Register 31044 AV: Ananlog Value 1329 HVAC//RTU HVAC//RTU HVAC//RTU
RTU Zone Temp. Sensor Fault 04:input Register 31045 AV: Ananlog Value 1330 HVAC//RTU HVAC//RTU HVAC//RTU
RTU Ambient Temp. Sensor Fault 04:input Register 31046 AV: Ananlog Value 1331 HVAC//RTU HVAC//RTU HVAC//RTU
