1.10. MCS Capacity Control State Chart
The values exposed in the capacity state relate to the descriptions in this table.
State Number Description
0 “UNIT IN POWER UP”
1 RESERVED
2 “NO RUN- I/O LOST”
3 “UNIT IN LOCKOUT “
4 “UNIT IS OFF “
5 “UNIT IS HOLDING “
6 “UNIT UNLOADING “
7 “UNIT IS LOADING “
8 “NO RUN–SAFETY “
9 “RUN/STOP SW OFF “
10 “SCHEDULED OFF “
11 “OFF-NO FLOW(s)”
State Number Description
20 “SAFETY TRIPPED”
21 “LO TEMP UNLOAD”
22 “LO TEMP HOLD “
23 “HI AMP HOLD “
24 “HI DIS TMP HLD”
25 “CMP IS AT 40% “
26 “CMP IS AT 70% “
27 “HI WATER HOLD “
28 “EXTRA 70% STEP “
29 “OFF-LO OIL TMP “
30 “HI AMP UNLDING “
31 “DEF PREPMP OUT “
32 “DEFROSTING “
33 “DEF PUMP DOWN “
34 “HI TEMP UNLOAD “
35 “HI TEMP HOLD “
36 “SCROLL STEP1 “
37 “SCROLL STEP2 “
38 “SCROLL STEP3 “
39 “SCROLL STEP4 “
12 RESERVED
13 “AMBIENT OFF “
14 “PROCESS HEAT OFF”
15 “UNIT IS UNLOADED”
16 “UNIT IS LOADED “
17 “OFF TMP-ICE MADE “
18 “ECONOMIZER ONLY “
19 “SWITCHING MODES “
20 “UNIT SMOKE UNLDG”
21 “UNIT OFF UNLDING”
22 “UNIT DMD UNLDING”
23 “UNIT HEAT UNLDNG”
1.11. MCS Compressor Control State Chart
The values expressed in the compressor state relate to the descriptions in this table.
State Number Description
0 “LOST IO LOCKED”
1 “CMP LOCKED OUT”
2 “SWITCHED OFF “
3 “CMP PUMP DOWN “
4 “CMP ANTICYCLE “
5 “CMP OFF/READY “
6 “OIL PMP LUBING”
7 “CMP IS RUNNING”
8 “CMP UNLOADED “
9 “UNLD1/HGBP OFF”
10 “PART LOADED “
11 “CMP IS HOLDING”
12 “CMP IS LOADING”
13 “CMP IS UNLDING”
14 “CMP IS AT 100%”
15 “FAST UNLOADING”
16 “LO SUCT UNLOAD”
17 “LO SUCT HOLD “
18 “HI DISC UNLOAD”
19 “HI DISC HOLD “
