MCS-MAGNUM-BMS REVISION 3.1
27
2.5. EXAMPLE NETWORK
2.5.1 Standalone MCS-Magnum
 MCS-Touch
 BMS (Johnson N2 or LonTalk or Bacnet MS/TP)
 Internet Access
2.5.2 MULTIPLE MCS-MAGNUM ENCLOSURES
Ethernet
Building
Management
System
MCS-Touch
Internet
Router
MCS-BMS-Gateway-NL
RS485 or
LonWorks
