Appendix A.4. LED Diagnostics for Bacnet Communications between the MCS‐BMS‐GATEWAYand
device
Note:PleaseseethediagrambelowforLEDLocations
A.3.1BacnetProtoCessorLED’s














––



–


Light Description
PWR
ThisisthepowerlightandshouldshowsteadygreenatalltimeswhentheMCS‐BMS‐GATEWAY
MCS‐BMS‐GATEWAYispowered.
SYSERR
(LED1)
TheSYSERRLEDwillflashonceonpowerupandflashonce15secondsafterpowerup.Asteadyred
lightwillindicatethereisasystemerrorontheMCS‐BMS‐GATEWAY.Ifthisoccurs,immediately
reporttherelated“systemerror”shownintheerrorscreenoftheRUI
interfacetoMicroControl
Systemsforevaluation.
COMM
ERR
(LED2)
TheCOMMERRLEDwillflashonceonpowerupandflashonce15secondsafterpowerup.Asteady
redlightwillindicateacommunicationerrorhasoccurred.Toestablishthecauseoftheerror,goto
theerrorscreenoftheRUIinterface.
Config
ERR
(LED3)
TheConfigERRLEDwillflashonceonpowerupandflashonce15secondsafterpowerup.Asteady
amberlightwillindicateaconfigurationerrorexistsintheactiveconfiguration.SeetheErrorScreen
intheRemoteUserInterfaceforadescriptionoftheconfigurationerror.
Node
Offline
(LED4)
TheNodeOfflineLEDwillflashonceonpowerupand flashonce15secondsafterpowerup.Ifthe
NodeOfflineLEDstaysonsolid,aNodeOfflineconditionhasoccurred.
RUN
(PIO)
TheRUNLEDwillstartflashing20secondsafterpowerindicatingnormaloperation.TheMCS‐BMS‐
GATEWAYwillbeabletoaccessRUINEToncethisLEDstartsflashing.
PICRUN
(LED5)
ThePICRUNLEDwillflashindicatingnormaloperation.
LONLED

RUN

SYSERR
COMERR
ConfigERR
Nodeoffline
PWR
PICRUN
PICERR
UNUSED
UNUSED
Figure20BacnetProtoCessorLED’s
