Electromagnetic
Environment - Guidance
Power frequency
(50/60 Hz)
Magnetic field
IEC61000-4-8
If incorrect operation
occurs, it may be
necessary to position the
MicroLab further from
sources of power
frequency magnetic fields
or to install magnetic
shielding. The power
frequency magnetic field
should be measured in the
intended installation
location to assure that it is
sufficiently low.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The MicroLab is intended for use in the electromagnetic environment specified below. The
customer or the user of the MicroLab should assure that it is used in such an environment.
Conducted RF
IEC61000-4-6
3 V
0,15 MHz – 80 MHz
6 V in ISM bands
Between 0,15 MHz and
80 MHz
80% MHz at 1 KHz
3 V
0,15 MHz – 80 MHz
6 V in ISM bands
Between 0,15 MHz and
80 MHz
80% MHz at 1 KHz
Radiated RF IEC
61000-4-3
IMMUNITY to
proximity fields
from RF wireless
communications
equipment IEC
61000-4-3
28 V/m
450 MHz, 50% PM at 18 Hz
810 MHz, 50% PM at 18 Hz
870 MHz, 50% PM at 18 Hz
930 MHz, 50% PM at 18 Hz
1720 MHz, 50% PM at 217 Hz
1845 MHz, 50% PM at 217 Hz
1970 MHz, 50% PM at 217 Hz
2450 MHz, 50% PM at 217 Hz
27 V/m
385 MHz, 50% PM at 18 Hz
9 V/M
710 MHz, 50% PM at 217 Hz
745 MHz, 50% PM at 217 Hz
780 MHz, 50% PM at 217 Hz
5240 MHz, 50% PM at 217 Hz
5500 MHz, 50% PM at 217 Hz
5785 MHz, 50% PM at 217 Hz
28 V/m
450 MHz, 50% PM at 18 Hz
810 MHz, 50% PM at 18 Hz
870 MHz, 50% PM at 18 Hz
930 MHz, 50% PM at 18 Hz
1720 MHz, 50% PM at 217 Hz
1845 MHz, 50% PM at 217 Hz
1970 MHz, 50% PM at 217 Hz
2450 MHz, 50% PM at 217 Hz
27 V/m
385 MHz, 50% PM at 18 Hz
9 V/M
710 MHz, 50% PM at 217 Hz
745 MHz, 50% PM at 217 Hz
780 MHz, 50% PM at 217 Hz
5240 MHz, 50% PM at 217 Hz
5500 MHz, 50% PM at 217 Hz
5785 MHz, 50% PM at 217 Hz
