6 | POWER PACK SERVICE MANUAL MICROMATIC.COM | 866-327-4159
EQUIPMENT SPECIFICATIONS
MODEL MMPP4305-PKG-3 MMPP4305-PKG-WC3 MMPP4307-PKG MMPP4307-PKG-WC MMPP4307-PKG-3
Type Air Cooled Water Cooled* Air Cooled Water Cooled* Air Cooled
BTUs* 7,250 7,250 11,500 11,500 11,500
Compressor HP 1 1 1 1/2 1 1/2 1 1/2
Glycol Pumps 3 3 2 2 3
Pump Type
Rotary Vane Rotary Vane Rotary Vane Rotary Vane Rotary Vane
Pump GPH 80 80 80 80 80
Pump Motor HP 1/3 1/3 1/3 1/3 1/3
Pump Inlet/Outlet Barbs 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8")
Plug Type
6-20P 6-15P 6-20P 6-20P 6-20P
Voltage
208/230 208/230 208/230 208/230 208/230
Amps (Running) 12.5A 11.4A 11.5A 9.9A 13.0A
Refrigerant R134a R134a R134a R134a R134a
Charge (oz.) 0.56 kg (20 oz) 0.56 kg (20 oz) 1.04 kg (37 oz) 1.04 kg (37 oz) 1.04 kg (37 oz)
Refrigerant
Running Pressures
18 (low)
140 (high)
18 (low)
140 (high)
55 (low)
260 (high)
55 (low)
260 (high)
55 (low)
260 (high)
Dimensions
L x W x H Including
pump(s) and motor(s)
37.12" x 18.75" x 31.5" 37.12” x 28.75” x 31.5” 38" x 20" x 36" 37.12” x 18.75” x 31.5” 38" x 30" x 36"
Weight (lbs) 131 kg / 290 lbs 98 kg / 215 lbs 134 kg / 295 lbs 134 kg / 295 lbs 134 kg / 295 lbs
Bath Capacity (gal) 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L
Bath Insulation
Thickness
1.5" 1.5" 1.5" 1.5" 1.5"
Inlet Water Pressure NA
Min 40 psi
Max 120 psi
NA
Min 40 psi
Max 120 psi
NA
Water Inlet & Outlet Fitting NA 9.52mm (3/8") NA 9.52mm (3/8") NA
Minimum Water Pipe Size NA 3/8" NA 3/8" NA
Approval
ETL Listed ETL Listed ETL Listed ETL Listed ETL Listed
*Rated at 20° F evaporator temperature and 90° F ambient temperature. †.3GPM, water is only used when the temperature of the condenser rises high enough to open the cooling
inlet valve. This is approximately 40% of the operating time depending on the ambient temperature and usage. Condenser Inlet Water Temperature: Minimum 45° F / Maximum 80° F
