MICROMATIC.COM | 866-327-4159 POWER PACK SERVICE MANUAL | 7
EQUIPMENT SPECIFICATIONS
MODEL MMPP4307-PKG-3-WC MMPP4307-PKG-4 MMPP4307-PKG-4-WC
Type Water Cooled* Air Cooled Water Cooled*
BTUs* 11,500 11,500 11,500
Compressor HP 1 1/2 1 1/2 1 1/2
Glycol Pumps 3 4 4
Pump Type
Rotary Vane Rotary Vane Rotary Vane
Pump GPH 80 80 80
Pump Motor HP 1/3 1/3 1/3
Pump Inlet/Outlet Barbs 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8")
Plug Type
6-15P 6-20P 6-20P
Voltage
208/230 208/230 208/230
Amps (Running) 11.4A 14.5A 14.5A
Refrigerant R134a R134a R134a
Charge (oz.) 1.04 kg (37 oz) 1.04 kg (37 oz) 1.04 kg (37 oz)
Refrigerant
Running Pressures
55 (low)
260 (high)
55 (low)
260 (high)
55 (low)
260 (high)
Dimensions
L x W x H Including
pump(s) and motor(s)
37.12" x 18.75" x 31.5" 38" x 30" x 36" 37.12" x 28.75" x 31.5"
Weight (lbs) 134 kg / 295 lbs 134 kg / 295 lbs 134 kg / 295 lbs
Bath Capacity (gal) 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L
Bath Insulation
Thickness
1.5" 1.5" 1.5"
Inlet Water Pressure
Min 40 psi
Max 120 psi
NA
Min 40 psi
Max 120 psi
Water Inlet & Outlet Fitting 9.52mm (3/8") NA 9.52mm (3/8")
Minimum Water Pipe Size 3/8" NA 3/8"
Approval
ETL Listed ETL Listed ETL Listed
*Rated at 20° F evaporator temperature and 90° F ambient temperature. †.3GPM, water is only used when the tempera-
ture of the condenser rises high enough to open the cooling inlet valve. This is approximately 40% of the operating time
depending on the ambient temperature and usage. Condenser Inlet Water Temperature: Minimum 45° F / Maximum 80° F
