MICROMATIC.COM | 866-327-4159 REMOTE POWER PACK SERVICE MANUAL | 5
EQUIPMENT SPECIFICATIONS
MODEL MMPP4305-PKG-3-R MMPP4307-PKG-R MMPP4307-PKG-R MMPP4307-PKG-4-R
Type Air Cooled Air Cooled Air Cooled Air Cooled
BTUs* 7,250 11,500 11,500 11,500
Compressor HP 1 1 1/2 1 1/2 1 1/2
Glycol Pumps 3 2 3 4
Pump Type
Rotary Vane Rotary Vane Rotary Vane Rotary Vane
Pump GPH
80 80 80 80
Pump Motor HP
1/3 1/3 1/3 1/3
Pump Inlet/Outlet Barbs 9.52mm (3/8”) 9.52mm (3/8”) 9.52mm (3/8”) 9.52mm (3/8”)
Plug Type
6-15P 6-15P 6-15P 6-15P
Condensing Unit
Electrical Requirement
208/230V /20A 208/230V /20A 208/230V / 20A 208/230V / 20A
Refrigerant R134a R404a R404a R404a
Refrigerant
Running Pressures
18 (low) / 140 (high)
55 (low)
260 (high)
55 (low)
260 (high)
55 (low)
260 (high)
Dimensions
L x W x H Including
pump(s) and motor(s)
37.12” x 18.75” x 31.15” 38” x 20” x 36” 38” x 30” x 36” 30" x 18" x 29.75"
Weight (lbs) 131 kg / 290 lbs 134 kg / 295 lbs 134 kg / 295 lbs 91 kg / 200 lbs
Bath Capacity (gal) 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L
Bath Insulation
Thickness
1.5" 1.5" 1.5" 1.5"
Inlet Water Pressure NA NA NA NA
Water Inlet & Outlet Fitting NA NA NA NA
Minimum Water Pipe Size NA NA NA NA
Approval
ETL Listed ETL Listed ETL Listed ETL Listed
*Rated at 20° F evaporator temperature and 90° F ambient temperature. †.3GPM, water is only used when the temperature of the
condenser rises high enough to open the cooling inlet valve. This is approximately 40% of the operating time depending on the ambi-
ent temperature and usage. Condenser Inlet Water Temperature: Minimum 45° F / Maximum 80° F
