dsPIC33/PIC24 Family Reference Manual DS30009740B-page 40  2010-2013 Microchip Technology Inc.
14.0 REGISTERS
Table 14-1: Special Function Registers Associated with LCD Driver Module
Name Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
LCDCON LCDEN
— LCDSIDL — — — — — — SLPEN WERR CS1 CS0 LMUX2 LMUX1 LMUX0
LCDPS
— — — — — — — — WFT BIASMD LCDA WA LP3 LP2 LP1 LP0
LCDREF LCDIRE
— LCDCST2 LCDCST1 LCDCST0 VLCD3PE VLCD2PE VLCD1PE LRLAP1 LRLAP0 LRLBP1 LRLBP0 — LRLAT2 LRLAT1 LRLAT0
LCDREG CPEN
— — — — — — — — — BIAS2 BIAS1 BIAS0 MODE13 CKSEL1 CKSEL0
LCDSEx LCD Segment x Pin Enable Registers
LCDDATAx LCD Data x Registers
IFS6
— — — — — — — — — — — LCDIF — — — —
IEC6
— — — — — — — — — — — LCDIE — — — —
IPC25
— — — — — — — — — — — — — LCDIP2 LCDIP1 LCDIP0
Legend: — = Unimplemented bit; r = Reserved bit
