DS50002449A-page 32  2016 Microchip Technology Inc.
21 7 FB1, FB2, FB3,
FB4, FB5, FB7,
R59
Ferrite bead, 150
ohms at 600 MHz
3216 metric Steward/Laird
HI1206N101R-10
22 3 JP1, JP2, JP4 JUMPER Header 2x1, standard 25 mil header pins, 100 mil pitch
23 1 JP3 3X1 Header 3x1, standard 25 mil header pins, 100 mil pitch
24 1 J6 RJ-45 Jack RJ45-4P TE 5558342-1
25 DNI 1 J1 RJ-45 Jack RJ45-4P TE 5558342-1
26 DNI 1 J2 MQS 4 Pos TE
1379165-1
1379165 TE 1379165-1
27 DNI 1 J3 Sumitomo 6098-6793 6098-6793 Sumitomo 6098-6793
28 DNI 1 J4 Female MII Connec-
tor, SCSI-2, 40-pin
Thru hole TE 5787170-4
29 1 J5 Male MII Connector,
SCSI-2, 40-pin
PCB edge mount Goal Ray Industry Co. Ltd
MDS-40MM-3-C2
30 1 J7 Header 5x2 HDR 5x2, standard
25mil header pins,
100mil pitch
FCI 67997-410HLF
31 1 J8 DC power connector,
barrel, 2.1 mm
Thru hole CUI PJ-002A
Switchcraft RAPC722X
32 DNI 1 J9 Terminal block, 2 term Thru hole Phoenix 1984617
33 1 L1 TDK ZJYS81 ZJYS81 TDK ZJYS81R5
34 2 L2, L3 Common mode
choke for signals
4532 metric 4ld TDK ACT45B-101-2P
35 DNI 9 R1, R2, R3, R4,
R5, R6, R60, R91,
R92
Opt/0 0603
36 26 R11, R12, R13,
R14, R15, R16,
R21, R22, R23,
R24, R25, R26,
R62, R81, R211,
R212, R213,
R214, R215,
R216, R221,
R222, R223,
R224, R225, R226
0 0603
37 14 R20, R29, R30,
R64, R65, R66,
R67, R82, R83,
R84, R85, R86,
R87, R88
33 0402
38 1 R35 1K 0603
39 DNI 7 R36, R37, R38,
R39, R44, R70,
R93
Opt/4.7K 0603
40 11 R40, R41, R42,
R46, R51, R68,
R69, R74, R78,
R89, R99
4.7K 0603
41 DNI 4 R43, R71, R72,
R73
Opt/1K 0603
42 1 R45 6.49K 0603
TABLE B-1: BILL OF MATERIALS (BOM) (CONTINUED)
Item Quantity Reference Description Footprint/Package Manufacturer/Part Number
