KSZ8061MNX EVALUATION
BOARD USER’S GUIDE
2016 Microchip Technology Inc. DS50002449A-page 7
Preface
INTRODUCTION
This chapter contains general information that will be useful to know before using the
KSZ8061MNX Evaluation Board. Items discussed in this chapter include:
• Document Layout
• Conventions Used in This Guide
• Recommended Reading
• The Microchip Web Site
• Customer Support
• Revision History
DOCUMENT LAYOUT
This document describes how to use the KSZ8061MNX Evaluation Board as a devel-
opment tool. The document is organized as follows:
• Chapter 1. “Product Overview” – This chapter includes important information
about the KSZ8061MNX Evaluation Board.
• Chapter 2. “Configuration” – This chapter includes a detailed description of
each function of the evaluation board and instructions on how to begin using the
board.
• Appendix A. “Schematic and Layouts” – Refer to this appendix for board
schematics.
• Appendix B. “Bill of Materials (BOM)” – Refer to this appendix to view the bill of
materials.
NOTICE TO CUSTOMERS
All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our web site
(www.microchip.com) to obtain the latest documentation available.
Documents are identified with a “DS” number. This number is located on the bottom of each
page, in front of the page number. The numbering convention for the DS number is
“DSXXXXXXXXA”, where “XXXXXXXX” is the document number and “A” is the revision level
of the document.
For the most up-to-date information on development tools, see the MPLAB
®
IDE online help.
Select the Help menu, and then Topics to open a list of available online help files.
To Next Page
