Microcom 226 - Figure 10 ^D326-List Settings Example; Figure 11 ^D325-List Selections Example; Printer Modes

Chapter 4 Printer Modes
226/426 User’s Guide 27
Figure 10 ^D326-List Settings Example
Figure 11 ^D325-List Selections Example
Settings (D326 or <Ctrl> V)
Operational
Print Speed: (D635) 6.0 ips
Detector mode: (D636) 0 (none)
Slew Speed: (D645) 6.0 ips
Darkness: (D690) 75 (Dark)
Retraction delay: (D641) 0.5 sec.
Print delay: (D640) 0.0 sec.
Labels printed: (D655) 42
Distances
Label width (LSX): (D631) 3.34 inches
Label height (LSY): (D632) 1.5.12 inches
Reg. mark height (GAP): (D633) 0.148 inches
To reg’n mark (DRM): (D634) 0.0 inches
X offset (OFX): (D637) 0.0 inches
Y offset (OFY): (D638) 0.0 inches
Dist. Past Gap (DPG): (Auto) 1.225 inches
Activate Gap Det (AGD) (Auto) 0.0 inches
Advance/retract: (D642) 0.512 inches
Serial port settings (D670) 9600,N,8,1
Ethernet Active at 10/100
MAC: 0x000257795634
Printer IP: (D675) 192.168.200.3
Server/Host IP: (D675) 192.168.200.1
Gateway IP: (D675) 192.168.200.1
Broadcast Mask: (D675) 192.168.200.255
Net Mask: (D675) 255.255.255.0
USB port settings Not installed
Thresholds
Gap: 29
Black line: 98
Stock: 110
High head temperature: 147
Low head temperature: 24
PWM periods
Gap: 64
Black line: 41
Label Present: 64
Stacker: 64
NOTE: Some items may not be correct until after a scripted
label is printed or Auto-size (D310) is run.
Selections (D325 or <Ctrl> U)
Operational
Dispense mode: (D597) 3
Emulation: (D501) Microcom 426
Cutter Type: (D506) NONE
PMH Type: (D507) NONE
Button Mode: (D541) 1
Response Mode: (D550) verbose
Automatic responses: (D580) Errors
Power-up label: (D586) 1
Detector mode: (D636) 0 (none)
General
Measurement units: (D564) 1 (inches)
Speed units: (D565) 1 (ips)
Temperature units: (565) 1 (Fahrenheit)
