Chapter 5 Communications
226/426 User’s Guide 31
Figure 12 426 Interface Connections
Figure 13 Ethernet Port - 10BASE-T
(A)
(B)
(C)
10BASE-T Ethernet Port
Auxiliary Port
RS-232 Serial Port
