Maintenance and Adjustments Chapter 6
36 226/426 User’s Guide
Figure 16 Removal of top cover
Figure 17 Unlatching of Print head
(A)
(A)
CAUTION: Unplug the power cord before removing the printer
covers to avoid possible personal injury or damage to the printer.
