MicroCool IBEX Series - Before Starting; Crankcase Oil Plug; Oil Level; Inlet Water Supply Pressure

IBEX 8 Nozzle SMALL FRAME_June 2020 June 20 Page 5 of 41
WARNING!!
PLEASE TAKE NOTE OF THE FOLLOWING
1. BEFORE STARTING
PLEASE READ THIS GUIDE ENTIRELY BEFORE BEGINNING INSTALLATION
ALSO, READ SUPPLEMENTAL INFORMATION RELATING TO OPTIONAL CONTROL EQUIPMENT
CRANKCASE OIL PLUG
The pump module crankcase vent has been plugged to prevent accidental oil leakage during shipment. Remove
the plug and replace with the supplied vent cap before operating pump unit. Failure to do so will cause oil leaks.
OIL LEVEL
Check that the oil level appears 1/2 way in the sight gauge or within range on the dipstick in the pump head.
INLET WATER SUPPLY PRESSURE.
When the pump module is running, it must be supplied with an inlet water supply of
NEVER LESS THAN 20 P.S.I. (1.40 BAR) AND NEVER MORE THAN 90 P.S.I. (6.20 BAR)
• INLET WATER SUPPLY PRESSURE SHOULD BE STEADY AND SHOULD NOT BE ALLOWED TO FLUCTUATE OUTSIDE OF THESE
RANGES
. FAILURE TO DO SO CAN RESULT IN DAMAGE TO EQUIPMENT AND IS NOT COVERED BY WARRANTY.
• IF WATER PRESSURE DROPS BELOW 20 PSI, THE PUMP WILL SHUT OFF AND THE FAULT LIGHT WILL COME ON. SEE SECTION
9 SYSTEM OPERATION FOR FUTHER INFORMATION.
OIL CHANGE INTERVAL
The crankcase oil must be changed after the first 50 hours of operation and from then on, once every 500 hours.
• SYNTHETIC 75W-90 GEAR OIL IS RECOMMENDED FOR ALL APPLICATIONS (MOBILE ONE OR EQUAL)
• SECONDARY CHOICE SYNTHETIC 15W-50 MOTOR OIL MAY BE USED FOR ALL APPLICATIONS (MOBILE ONE OR EQUAL)
HIGH PRESSURE FITTINGS
The system operates at 1,000 P.S.I. (70 bar) and should always be shut down when working on fittings or manifold
line. Extreme caution should always be exercised when working with high pressure water. Always wear safety glass
when working around fog equipment.
INLET WATER SUPPLY PLUMBING MATERIAL
Only rated and approved brass fittings or stainless steel fittings should be used to make plumbing connections. The
use of galvanized or steel pipe fittings can cause system failure, nozzle blockage and pump damage.
FLUSHING THE SYSTEM
Before pressurizing the system, flush all plumbing and atomization lines thoroughly to purge any residual debris.
Please refer to the startup section 7 of this manual.
TEFLON TAPE
When using Teflon tape on NPT threads, leave 1 or 2 of the starting threads showing. This will prevent pieces of
Teflon tape from entering the system, which could cause blockage or damage.
