Microlife BP A1 Easy User Manual

8
This device complies with the requirements of the Medical Device
Directive 93/42/EEC.
Technical alterations reserved.
Measurement range: 20 - 280 mmHg – blood pressure
20 - 200 beats per minute – pulse
Cuff pressure display
range: 0 - 299 mmHg
Resolution: 1 mmHg
Static accuracy: within ± 3 mmHg
Pulse accuracy: ± 5 % of the readout value
Voltage source:
4 x 1.5 V alkaline batteries; size AA
Mains adapter DC 6V, 600 mA (optional)
Battery lifetime: approx. 920 measurements
(using new batteries)
IP Class: IP 20
Reference to
standards:
EN 1060-1 /-3 /-4; IEC 60601-1;
IEC 60601-1-2 (EMC); IEC 60601-1-11
Expected service life: Device: 5 years or 10000 measurements,
whichever comes first
Accessories: 2 years or 5000 measure-
ments, whichever comes first

Microlife BP A1 Easy Specifications

General

Type	Automatic
Cuff size	22 - 42 cm
Placement supported	Upper arm
Pulse rate measuring	Yes
Mean arterial pressure	-
Display type	LCD
