FlowPrep 060 Specifications
May 2010 1-3
Specifications
The following table gives the specifications of the FlowPrep 060 Degasser.
Table 1-1. Specifications
Characteristic Specification
Sample Tubes Up to 3.0-cm (1.18-in.) OD
Heating Block
Temperature:
Temperature Accuracy:
10 ºC above ambient to 400 ºC
± 10
o
C
Electrical
Voltage:
Power:
Frequency:
100, 120, 220, 240 VAC ± 10%
250 VA maximum
50/60 Hz
Environment
Temperature:
Humidity:
10 to 35 ºC operating; 0 to50 ºC non-operating
45 to 80% relative, non-condensing
Gases Used Helium, nitrogen, argon, or any other pure gas that does
not adsorb at room temperature
Flow Rate
Up to 50 cm
3
/min. No vacuum required
Sample Capacity 6 heating stations and 6 cooling stations
Physical
Height:
Width:
Depth:
Weight:
45 cm (16.93 in.)
36 cm (14.17 in.)
30 cm (11.81 in.)
8.6 kg (19 lbs)
