Micron Q1068A - Measure Capacitance

11
4. To test diodes, connect the red probe to the anode
side and the black probe to the cathode side of
the diode being tested. Then read the forward bias
voltage value on the display. If the polarity of the
test leads is reversed with diode polarity or the
diode is broken, the display reading shows “ ”.
Measure Capacitance
1. Connect the black test lead to the COM Terminal and
the red lead to the Terminal;
2. Turn the rotary to , press “SELECT” to the
capacitance Mode;
3. Connect the red probe to the anode side and the
black probe to the cathode side of the diode being
tested;
4. Read the measured capacitance value on the
display once the reading is stabilized.
*Do not input voltage at this setting.
*Disconnect circuit power and discharge all
capacitors before you test diode.
*Disconnect circuit power and discharge all
capacitors before you test diode.
