Measure Frequency and Duty Cycle

1. Connect the black test lead to the COM Terminal and

the red lead to the Terminal;

2. Turn the rotary switch to , press SELECT

to frequency test function (≥10V，1~100KHz); or

turn the rotary switch to , press SELECT

to frequency test function (≤10V，1~5MHz);

3. If the frequency between 100kHz and 5MHz,

press SELECT to enter AC mV position. Touch

the probes to the desired test points, now the vice

display will show frequency; Then press the

SELECT again, the main display will show

frequency and vice display will show duty cycle.
