Area B entry delay (1 digit)
As above
Area A alternate entry delay (1 digit)
As above
Area B alternate entry delay (1 digit)
As above
Siren output timer (1 digit)
Erased: no timeout
1-15: 1 to 15 minutes
Aux. output 1 timer (1 digit) As above
Aux. output 2 timer (1 digit) As above
Zone swinger shutdown count (1 digit)
1-7: one to seven activations
Rings before answering (1 digit)
Call attempts before communication failure (1 digit)
Erased: Communicator disabled
1-15: number of dialing attempts
Call attempt timer 1- 15, anti jam (1 digit)
Times 10 seconds
Line test mode
Erased: no line test
1: Tests at all times
2: Tests when away armed only (recommended)
3: Tests when away or night armed
Looks to area A
(the system area) to
determine arm state.
Default (erased – no
line test)
Cross zones mode (1 digit)
Erased: No cross mode
1: Same zone twice
2: Different zones
3: Either same or different zones
Cross zones timer (1 digit)
Erased: 30 seconds
1-15: 1-15 minutes
Zone 1 filter (1 digit)
Erased: 10mS
1: 20mS
2: 40mS
3: 80mS
4: 160mS
5: 320mS
6: 640mS
7: 1.28 Seconds
Zone 2 filter (1 digit) As above
Zone 3 filter (1 digit) As above
Zone 4 filter (1 digit) As above
Zone 5 filter (1 digit) As above
Zone 6 filter (1 digit) As above
Zone 7 filter (1 digit) As above
Zone 8 filter (1 digit) As above
Area A zones select (toggle)
Select zones for this area. Zones selected in both
areas become common zones
Z4120C 1 – 4
Z6020C 1 – 6
Z8020C 1 – 8
Area B zones select (toggle)
As above
Reserved – do not program
Key-switch zones select (toggle)
Key-switch controlled area is defined by Loc. 374
Smoke / 24-hour zones select (toggle)
Night or instant arming zones select (toggle)
