122 Operator Maintenance
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F40 Edition 1.1
!
Nut
12. Fix the auxiliary rod at the drum shaft.
Auxiliary rod
Drum shaft
Do not touch the drum surface because the material is easy to
damage.
