Microplex SOLID F40 - Page 57

Panel Functions 57
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F40 Edition 1.1
Example: The printer processes fanfold paper with a width of 297mm (A4
landscape). When the Two-Up mode is chosen each time 2 images of
A5 are printed side by side.
Note: All other page parameters have to be set optionally in accordance to the
requirements.
A simultaneous combination of several print images per formlength and
several print images per form width isn’t possible until now.
print print
image 1 image 2
A5 A5
form width A4 landsca
p
e
print direction
(paper feed direction)
