MicroPower MTM - Thyristor Control PCB (6-Pulse Bridge Only)

17 (30)
Document no.
99-99-111
Version
6
Date
2003-10-16
Sign.
ToNo
4.2 Thyristor control PCB (6-pulse bridge only)
Connection Function
J1 Power supply for optional pcb (I/O-pcb, IDB-transceiver)
J2 Power supply from Main PCB
J3 Gate control signal from Main PCB
J4 Shunt Input/Output
J5 Thyristor gate output
J6 Power supply for IDB communication PCB
J7 I2C-bus
J8 I2C-bus
J9 Thyristor test
Thyristor
active LED
