5 APPENDICES
Wiring diagrams, spares lists, program descriptions, etc. are gathered under this
heading.
The program version appears on a label stuck to the program circuit located in sockets
on the computer card. Information on the program version installed can also be viewed
in the first screen for the menu system.
5.1 Tables
5.1.1 Adaptation to model.
Function Description Value
Mains voltage code 3-phase 5-wire (3-phase + neutral + earth) Y-
coupled transformers without aux. transformer.
0
3-phase 4-wire (3-phase + earth) delta-coupled
transformers with or without aux. transformer
0
3-phase 4-wire (3-phase + earth) Y-coupled
transformers with aux. transformer
1
System current code Rated current < 100A, shunt 75A/50mV 1
100-150A, shunt 150A/50mV 2
> 150A, shunt 2x150A/50mV 4
System voltage code System voltage < 24VDC 0
24 - 48VDC 1
72 - 120VDC 2
240VDC 3
System RI (m)
Rated current 40A
16,5m
50A 10,0m
60A
10,0m
80A
7,0m
100A
5,0
125A
4,0m
150A 4,0m
175A
3,0m
200A
2,0m
225A 2,0m
250A
1,0m
